Technical Data - Bosch GCM 350-254 Professional Originalbetriebsanleitung

(2) Adjustable fence
(3) Standard bevel angle stops 47°, 45°, 33.9° and
22.5° (vertical)
(4) Scale for bevel angles
(5) Angle indicator for right-hand bevel angle range
(6) Locking screw for slide device
(7) Clamping lever for all bevel angles
A)
(8) Speed regulator
(9) Transport safety lock
(10) Transport handle
(11) Protective guard
(12) Handle
(13) Locking lever
(14) Laser protection cap
(15) Retracting blade guard
(16) Guide roller
(17) Assembly holes
(18) Saw table
(19) Insert plate
(20) Locking clamp
(21) Locking knob for all mitre angles
(22) Mitre pre-setting lever
Tilt protector
(23)
(24) Angle indicator for mitre angles
(25) Detents for standard mitre angles
(26) Scale for mitre angles
(27) Saw table extension
(28) Recessed handles
(29) Holes for screw clamp
(30) SDS bolt
(31) On/off switch
(32) On/off switch for laser (cutting line indication)
(33) Laser warning label
(34) Chip ejector
(35) Locking screw for the adjustable fence
(36) Slide device
(37) Hex key (6 mm/4 mm)

Technical Data

Sliding mitre saw
Article number
Rated power input
No-load speed
Starting current limitation
Laser type
Bosch Power Tools
(38)
(39)
(40)
(41)
(42)
(43)
(44)
(45)
(46)
(47)
(48)
(49)
(50)
(51)
(52)
(53)
(54)
(55)
(56)
(57)
(58)
(59)
(60)
(61)
(62)
(63)
(64)
(65)
(66)
(67)
(68)
(69)
(70)
A) Not available in all country-specific versions.
B) Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.
GCM 350-254 GCM 350-254
3 601 M22 6.. 3 601 M22 640
W 1800
-1
min 3700–5000 3700–5000
●
nm 650
mW < 0.39
Screw clamp
Depth stop adjusting screw
Depth stop
Angle indicator for left-hand bevel angle range
Stop for standard 0° bevel angle
Chip deflector
Spindle lock
Hex socket screw for mounting the saw blade
Clamping flange
Saw blade
Inner clamping flange
Clamping screw for saw table extension
Threaded rod
Wing bolt
Laser beam outlet aperture
B)
Vertical distance stop
B)
Horizontal distance stop
Screws for insert plate
B)
Length stop
B)
Locking screw for length stop
B)
Clamping screw for length stop
Set screw for laser positioning (right of the saw
blade)
Hex key (2.5 mm)
Set screw for laser positioning (left of the saw
blade)
Screw for laser protection cap
Fastening screw for laser mounting plate
Fastening screw for laser housing
Stop screw for 0° bevel angle
Stop screw for left-hand bevel angle range
Stop screw for right-hand bevel angle range
Set screws for mitre angle scale
Screw for mitre angle indicator
Hook-and-loop strap
GCM 350-254 GCM 350-254
3 601 M22 660 3 601 M22 6B0
1800 1450
4600
● –
650 650
< 0.39 < 0.39
1 609 92A 5UA | (06.10.2020)
English | 33
1800
3700–4600
●
650
< 0.39
