ACHTUNG
Zu hohes Gewicht.
Verlust der Kontrolle über den Traktor.
Schwere oder tödliche Verletzungen.
-
Sicherstellen, dass das zulässige Anbaugewicht
des Traktors nie überschritten wird.
Vor der Regulierung der Hubarme den Motor anhalten
und die Handbremse ziehen.
Zum Umschalten von der „Straßenposition" (A) auf die
„Arbeitsposition" (B) ist wie folgt vorzugehen:
- Den Bolzen (1) herausziehen.
- Den Hubarm absenken.
Arbeitsstellungen
-
Hubarm in fixer Arbeitsstellung (A).
-
Hubarm in schwimmender Arbeitsstellung (B).
-
Den Bolzen (1) wieder montieren.
revision 0 date: 07/19 doc. AG525995
CAUTION
Load too heavy.
Loss of tractor control. Death, serious
injuries.
-
Ensure that the tractor's maximum authorised
hitch load is never exceeded.
Stop the engine and apply the hand brake before
carrying out any adjustments on the lift arms.
To change from "road" position (A) to "work" position (B):
- Extract the pin (1).
- Lower the lift arm.
Working positions
-
Arm in fixed working position (A).
-
Arm in floating working position (B).
-
Refit the pin (1).
5
