Values
You use this type of depiction to show one or two currently measured values clearly.
The currently measured value is displayed. You cannot navigate between measured values.
You can stop and restart the measurement process.
You can carry out an empty adjustment.
1. Press the Measurement mode display or the gearwheel symbol to display the graph instead of
the table.
Settings
Value
1. Press one of the two list fields to select the measured values to be displayed.
2. Choose from the following:
– Moisture
– Density
– Temp. (temperature)
– Off (no display, only possible in the second panel).
3. Choose from the following:
– Last
The last determined and stored value is displayed. In certain circumstances, this value is an av-
erage of several measurements.
– Status line
The value displayed in the status line is shown. This value corresponds to the currently measured
value. In some circumstances, this value is not stored.
This setting applies to both displays.
4. Press Apply. The values are displayed in accordance with the selected settings.
