Assembly and connection
5.4 Hydraulic installation
5.4.1 Connecting the water supply
WARNING!
Contamination of the water supply network by chemicals harmful to
health
In the event of a system fault, dosing chemicals could enter the public water
supply network.
– Connect suitable on-site safety systems for protecting the water supply
network (e.g. system disconnectors or Ecolab Maxi Quick Fill) upstream.
– Observe local requirements for the protection of the drinking water system.
Fig. 8: Connecting the water supply
1.
Screw a hose nipple D.10 G1/2a PP onto the mud guard
2. Feed the water hose
3. Slide a suitable hose clamp
4. Attach the water hose to the hose nipple and secure with the hose clamp.
MAN053089 Rev. 1-11.2023
1
2
3
4
into the unit through the hole in the drip pan
3
onto the water hose.
2
42
Mud guard
1
Hose clamp
2
Water supply hose
3
Drip pan
4
.
1
.
4
