Extending the Safety Program – Application Examples

5.2.1 Parameter description

Input parameter
REQ
TR_Hardware_ID
Output parameter
BUSY
VALID
ERROR
ERRVAL
STATUS
TR_Manuf_Error
 TR-Electronic GmbH 2016, All Rights Reserved
Page 142 of 159
Data type Description
Starts reading of the manufacturer-specific
BOOL
diagnosis.
Hardware identifier of the measuring system
HW_IO from which the diagnostic data are to be read
out.
Data type Description
Indicates whether the block is reading out the
BOOL
manufacturer-specific diagnosis.
Indicates whether reading of the manufacturer-
BOOL
specific diagnosis was successfully completed.
Indicates whether reading of the diagnosis
BOOL
ended with an error.
Indicates the error value which occurred during
asynchronous reading via the RDREC block.
DWORD
Analysis of the error using the help function in
TIA Portal V13.
Indicates the result for execution of the
manufacturer error block.
0x0000 = initialization value / manufacturer--
specific diagnosis is being read
0x0001 = manufacturer-specific error present
WORD 0x0002 = no manufacturer-specific error
present
0x0003 = error: asynchronous reading
0x0004 = error: incorrect length of
asynchronous read buffer
0x0005 = error: diagnosis ID is wrong
DWORD 4 byte value with manufacturer-specific error
