5.1.1 Parameter description

Input parameter
REQ
NEW_PRES_MULTI
NEW_PRES_SINGLE
TR_QBAD
TR_IPAR_OK
TR_Pres_Error
Output parameter
BUSY
VALID
ERROR
TR_IPAR_EN
TR_Pres_Multi
TR_Pres_Single
TR_Pres_Request
 TR-Electronic GmbH 2016, All Rights Reserved
Page 132 of 159
Data type Description
BOOL Starts the preset adjustment function
New multi-turn value to be
INT
set.
New single-turn value to be
INT
set.
Passivation bit of the measuring system.
In the example import F00000_CD_75_-
BOOL
EPNI/Osafety_1 [DB30002] from
measuring system F-IO data block.
Indicates whether the execution of the preset
adjustment function has been completed.
In the example import F00000_CD_75_-
BOOL
EPNI/Osafety_1 [DB30002] from
measuring system F-IO data block.
Indicates whether an error has occurred during
execution of the preset adjustment function.
BOOL
Import in measuring system input data from
register TR-Status at Pin 2
Data type Description
Indicates whether the block is currently
BOOL
executing the preset adjustment function.
Indicates whether the execution of the preset
BOOL adjustment function was successfully
completed.
Indicates whether the execution of the preset
BOOL
adjustment function ended with an error.
Sets the measuring system to Ready to
receive for the preset adjustment function.
In the example output F00000_CD_75_-
BOOL
EPNI/Osafety_1 [DB30002] to measuring
system F-IO data block.
Preset multi-turn value for the measuring
system. Output in the measuring system
INT
output data to Preset Multi-Turn register.
Preset single-turn value for the measuring
system. Output in the measuring system
INT
output data to Preset Single-Turn
register.
Ensures transfer of the preset value to the
measuring system.
BOOL
Output in the measuring system output data to
register TR-Control1 at Pin 2
