6.2.1 Measuring system F-IO data block "DB30002" - Overview of tags

Tags
PASS_ON
ACK_NEC
ACK_REI
IPAR_EN
PASS_OUT
QBAD
ACK_REQ
IPAR_OK
DIAG
6.2.1.1 PASS_ON
The tag PASS_ON = 1 can be used to activate a passivation of the safety-oriented data
of the CD_75_-EPN I/O safety_1 module, e.g. depending on defined states in the
safety program. The passivation is not performed directly in the measuring system,
instead the status of these tags is registered by the F-Host and the passivation is only
activated by means of the safety program data. Cyclical data are still output by the
measuring system!
If a passivation is performed with PASS_ON = 1, the preset adjustment function is
switched off.
6.2.1.2 ACK_NEC
This tag enables you to make a distinction between automatic reintegration and
reintegration with user acknowledgment after an F-Periphery error.
However, no process is defined for the measuring system, for which reintegration after
an F-Periphery error is permitted. For safety reasons these errors must be eliminated
first of all and the supply voltage must then be switched OFF/ON.
