Access to the safety-oriented data channel

5.2.1 Measuring system F-Periphery-DB "DB1638" - Overview of variables

Variable
PASS_ON
ACK_NEC
ACK_REI
IPAR_EN
PASS_OUT
QBAD
ACK_REQ
IPAR_OK
DIAG
QBAD_I_xx
QBAD_O_xx
5.2.1.1 PASS_ON
With the variable PASS_ON = 1 a passivation of the safety-oriented data of the
CD_75_-EPN E/A safety module can be activated, e.g. depending on defined
states in the safety program. The passivation is not performed directly in the
measuring system, instead the status of these variables is registered by the F-Host
and the passivation is only activated by means of the safety program data. Cyclical
data are still output by the measuring system!
If a passivation is performed with PASS_ON = 1, the preset adjustment function is
switched off.
5.2.1.2 ACK_NEC
The official application of this variable would be an operator acknowledgment for the
measuring system after F-I/O faults. However, for the measuring system no process is
defined, for which this procedure is permissible. For safety reasons these faults must
be removed first and then the supply voltage must be switched OFF/ON.
 TR-Electronic GmbH 2013, All Rights Reserved
Page 76 of 79
Data type Function
1 = Passivation of the cyclical data
BOOL of the CD_75_-EPN E/A safety
module via the safety program
1 = Operator acknowledgment in the
BOOL
event of F-I/O faults
1 = Operator acknowledgment after
BOOL communication errors or after the
start-up phase
Variable for execution of the preset
BOOL
adjustment function
BOOL Passivation output
BOOL 1 = Substitute values are output
1 = Acknowledgement request for
BOOL
the operator acknowledgment
1 = Execution of preset adjustment
BOOL
function successfully completed
Service information, only possible in
BYTE
the standard program
1 = Substitute values are output in
BOOL
input channel
1 = Substitute values are output in
BOOL
output channel
TR - ECE - TI - DGB - 0233 - 03
Access
read/write
default value: 0
read/write
default value: 1
read/write
default value: 0
read/write
default value: 0
read
read
read
read
read
read
read
Printed in the Federal Republic of Germany
