Laser Measuring Device
LE-200
_Zusätzliche Sicherheitshinweise
_Installation
_Inbetriebnahme
_Konfiguration / Parametrierung
_Fehlerursachen und Abhilfen
_Additional safety instructions
_Installation
_Commissioning
_Configuration / Parameterization
_Cause of faults and remedies
D
Seite 2 - 38
GB
Page 39 - 76
Benutzerhandbuch
User Manual
Werbung
Kapitel
Inhaltsverzeichnis
Verwandte Anleitungen für TR-Electronic LE-200
Inhaltszusammenfassung für TR-Electronic LE-200
- Seite 1 Seite 2 - 38 Page 39 - 76 Laser Measuring Device LE-200 _Zusätzliche Sicherheitshinweise _Installation _Inbetriebnahme _Konfiguration / Parametrierung _Fehlerursachen und Abhilfen _Additional safety instructions _Installation _Commissioning _Configuration / Parameterization _Cause of faults and remedies Benutzerhandbuch User Manual...
- Seite 2 Alle anderen genannten Produkte, Namen und Logos dienen ausschließlich Informationszwecken und können Warenzeichen ihrer jeweiligen Eigentümer sein, ohne dass eine besondere Kennzeichnung erfolgt. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 2 of 76...
-
Seite 3: Inhaltsverzeichnis
5.2 Einschalten der Versorgungsspannung .................. 22 6 Inbetriebnahme ..........................23 6.1 Gerätebeschreibungsdatei ...................... 23 6.2 Bus-Statusanzeige ........................23 TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... - Seite 4 10 Fehlerursachen und Abhilfen ....................... 37 10.1 Optische Anzeigen ........................ 37 10.2 Sonstige Störungen ......................38 TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 4 of 76 TR - ELE - BA - DGB - 0024 - 00...
-
Seite 5: Änderungs-Index
Änderungs-Index Änderung Datum Index Erstausgabe 21.01.16 TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00 Page 5 of 76... -
Seite 6: Allgemeines
Benutzerhandbuch, • und die bei der Lieferung beiliegende Montageanleitung TR-ELE-BA-DGB-0018 TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 6 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 7: Referenzen
IEEE 1588-2002 IEEE Standard for a Precision Clock Synchronization Protocol for Networked Measurement and Control Systems TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 8: Verwendete Abkürzungen / Begriffe
Objekt-Datenliste eines Gerätes. Extensible Markup Language, Beschreibungsdatei für die Inbetriebnahme des Mess-Systems. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 8 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 9: Zusätzliche Sicherheitshinweise
Beachten der Montageanleitung, insbesondere das dort enthaltene Kapitel "Grundlegende Sicherheitshinweise" muss vor Arbeitsbeginn gelesen und verstanden worden sein TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 10: Organisatorische Maßnahmen
Dies gilt in besonderem Maße für nur gelegentlich, z.B. bei der Parametrierung des Mess-Systems, tätig werdendes Personal. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 10 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 11: Technische Daten
Störfestigkeit: .......... DIN EN 61000-6-2 Störaussendung: ........DIN EN 61000-6-3 * parametrierbar über EtherCAT TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 12: Ethercat Informationen
Kommunikation eine logische Ringstruktur. Da Fast-Ethernet mit Voll-Duplex arbeitet, ergibt sich auch physikalisch eine Ringstruktur. Abbildung 1: EtherCAT-Funktionsprinzip TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 12 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 13: Protokoll
Damit können EtherCAT-Frames von beliebigen Ethernet-Controllern verschickt (Master), und Standard-Tools (z. B. Monitor) eingesetzt werden. Abbildung 2: Ethernet Frame Struktur TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 14: Geräteprofil
Protokoll, und damit das vom CANopen her bekannte „Device Profile for Encoder“, CiA DS-406. Abbildung 3: CANopen over EtherCAT Kommunikationsmechanismus TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 14 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 15: Canopen Over Ethercat (Coe)
Abbildung 5: EtherCAT eingeordnet im ISO/OSI-Schichtenmodell EN 50325-4: Industrielle-Kommunikations-Systeme, basierend auf ISO 11898 (CAN) für Controller-Device Interfaces. Teil 4: CANopen. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 16: Objektverzeichnis
Wichtige Merkmale von SDO und PDO Abbildung 7: Gegenüberstellung von PDO/SDO-Eigenschaften TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 16 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 17: Übertragung Von Sdo Nachrichten
Üblicherweise stellt der EtherCAT-Master entsprechende Mechanismen für die SDO-Übertragung zur Verfügung. Die Kenntnis über den Protokoll-Aufbau und internen Abläufe sind daher nicht notwendig. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 18: Pdo-Mapping
Stop Output Update, Stop Input Update Stop Input Update, Stop Mailbox Communication Stop Output Update, Stop Input Update, Stop Mailbox Communication TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 18 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 19: Weitere Informationen
+ 49 (0) 9 11 / 5 40 5629 Email: info@ethercat.org Internet: www.ethercat.org TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00 Page 19 of 76... -
Seite 20: Installation / Inbetriebnahmevorbereitung
Normen und Richtlinien zu beachten! Insbesondere sind die EMV-Richtlinie sowie die Schirmungs- und Erdungsrichtlinien in den jeweils gültigen Fassungen zu beachten! TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 20 of 76... -
Seite 21: Anschluss
15 21 26 1 Harting HARAX M12-L 21 03 281 1405 TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00 Page 21 of 76... -
Seite 22: Einschalten Der Versorgungsspannung
System während der Dienst-Ausführung keine plausiblen Werte ausgibt. Dies gilt für die Zustände SAFE-OPERATIONAL und OPERATIONAL. In der Regel werden die Mailbox-Zugriffe über SDO-Anforderungen ausgelöst. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 22 of 76... -
Seite 23: Inbetriebnahme
Fehler, Mess-System in Betrieb Mess-System-Fehler bzw. Hardwarefehler Entsprechende Maßnahmen im Fehlerfall siehe Kapitel „Optische Anzeigen“, Seite 37. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 24: Kommunikationsspezifische Objekte
Bit im „Status“ (Seite 26) im nächsten Zyklus wieder gesetzt. 8-15 unbenutzt Tabelle 1: RxPDO TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 24 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 25: Sende-Prozess-Daten-Objekt 1A00H (Txpdo)
Über dieses Eingangs-Byte wird die momentane Intensität des Laserstrahls in Prozent übertragen. Standardwert: 100 % = 0x64. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 26: Geschwindigkeit
Dies ist z.B. bei einem Positionssprung der Fall, wenn eine Messwert zweite Reflexionsfolie in den Laserstrahl gehalten wird. reserviert TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 26 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 27: Hersteller- Und Profilspezifische Objekte (Cia Ds-406)
Bit 0 = 0: Parameter werden nicht gespeichert Wert Bit 0 = 1: Parameter werden gespeichert Default TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 28: Objekt 2001H: Preset Löschen
Minimalwert Maximalwert 65 535 Default 100 dez. = 1 mm TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 28 of 76 TR - ELE - BA - DGB - 0024 - 00 01/21/2016... -
Seite 29: Objekt 2003H: Fehler Automatisch Quittieren
Bit 0 = 0: 10 mm/s, entspricht 0,01 m/s Wert Bit 0 = 1: 1 mm/s, entspricht 0,001 m/s Default TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 30: Objekt 2005H: Funktion Externer Eingang
Lebensdauer abgeschaltet. Fehlerquittierung: Schalteingang wird zur Quittierung von Fehlern benutzt. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 30 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 31: Objekt 2006H: Funktion Externer Ausgang
Der Schaltausgang wird gesetzt, wenn die Plausibilität des Messwertes nicht garantiert werden kann. Dies ist z.B. bei einem Positionssprung der Fall, wenn eine zweite Reflexionsfolie in den Laserstrahl gehalten wird. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016... -
Seite 32: Objekt 2007H: Fehlerwert
Bit 0 = 0: Funktionsauslösung mit steigender Flanke Wert Bit 0 = 1: Funktionsauslösung mit fallender Flanke Default TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 32 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 33: Objekt 200Ah: Laserdiode An- / Abschalten
Bit 0 = 0: Positionswerte steigend Wert Bit 0 = 1: Positionswerte fallend Default TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 34: Objekt 6003H: Presetwert
Byte 3 bis 2 bis 2 bis 2 bis 2 TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 34 of 76 TR - ELE - BA - DGB - 0024 - 00 01/21/2016... -
Seite 35: Objekt 6005H: Auflösung
* siehe „Objekt 2002h: Freie Auflösung“ auf Seite 28 Damit dieses Objekt dauerhaft gespeichert wird, muss „Objekt 2000h: Parameter übernehmen“ ausgeführt werden. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 36: Vom Mess-System Unterstütze Objekte Auslesen
● Button Erweitert klicken ● Radio-Button Online... auswählen ● --> Alle Objekte TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 36 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 37: Fehlerursachen Und Abhilfen
Wenn der Fehler trotz Hardwarefehler dieser Maßnahme wiederholt auftritt, muss das Mess-System getauscht werden. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 38: Sonstige Störungen
Erst nach dieser Zeit sollte der reguläre Anlagenbetrieb aufgenommen werden. Tabelle 4: Status-Bits TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 38 of 76 TR - ELE - BA - DGB - 0024 - 00... - Seite 39 User Manual LE-200 EtherCAT TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00 Page 39 of 76...
- Seite 40 All other specified products, names and logos serve exclusively for information purposes and may be trademarks of their respective owners, without any special marking to indicate this. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 40 of 76...
-
Seite 41: Contents
6 Commissioning ..........................61 6.1 Device description file ......................61 6.2 Bus status display ........................61 TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... - Seite 42 10 Error Causes and Remedies ......................75 10.1 Optical displays ........................75 10.2 Other faults ........................... 76 TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 42 of 76 TR - ELE - BA - DGB - 0024 - 00...
-
Seite 43: Revision Index
Revision index Revision Date Index First release 01/21/16 TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00 Page 43 of 76... -
Seite 44: General Information
User Manual, • and the Assembly Instructions TR-ELE-BA-DGB-0018 provided at delivery TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 44 of 76 TR - ELE - BA - DGB - 0024 - 00 01/21/2016... -
Seite 45: References
IEEE 1588-2002 IEEE Standard for a Precision Clock Synchronization Protocol for Networked Measurement and Control Systems TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 46: Abbreviations Used / Terminology
Extensible Markup Language, description file for commissioning the measuring system. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 46 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 47: Additional Safety Instructions
Assembly Instructions, particularly the chapter "Basic Safety Instructions" contained therein, must have been read and understood prior to commencement of work TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 48: Organizational Measures
User Manual, particularly the chapter "Additional Safety Instructions". This particularly applies for personnel who are only deployed occasionally, e.g. in the parameterization of the measurement system. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 48 of 76... -
Seite 49: Technical Data
Immunity to disturbance: ......DIN EN 61000-6-2 Transient emissions: ....... DIN EN 61000-6-3 * parameterizable via EtherCAT TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 50: Ethercat Information
As Fast-Ethernet works with Full Duplex, a physical ring structure also results. Figure 1: EtherCAT functional principle TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 50 of 76... -
Seite 51: Protocol
EtherCAT frames can thus be sent by any Ethernet controllers (master), and standard tools (e.g. monitor) can be used. Figure 2: Ethernet frame structure TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016... -
Seite 52: Device Profile
"Device Profile for Encoder", CiA DS-406, known from CANopen. Figure 3: CANopen over EtherCAT communication mechanism TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 52 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 53: Canopen Over Ethercat (Coe)
Figure 5: EtherCAT organized in the ISO/OSI layer model EN 50325-4: Industrial Communication Systems, based on ISO 11898 (CAN) for Controller Device Interfaces. Part 4: CANopen. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016... -
Seite 54: Object Dictionary
Important features of SDO and PDO Figure 7: Comparison of PDO/SDO characteristics TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 54 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 55: Transmission Of Sdo Messages
Normally the EtherCAT master provides appropriate mechanisms for the SDO transfer. Knowledge of the protocol structure and internal sequences is therefore not required. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 56: Pdo Mapping
Stop Output Update, Stop Input Update Stop Input Update, Stop Mailbox Communication Stop Output Update, Stop Input Update, Stop Mailbox Communication TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 56 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 57: Further Information
+ 49 (0) 9 11 / 5 40 5629 Email: info@ethercat.org Internet: www.ethercat.org TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00 Page 57 of 76... -
Seite 58: Installation / Preparation For Commissioning
In particular, the applicable EMC directive and the shielding and grounding directives must be observed! TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 58 of 76... -
Seite 59: Connection
15 21 26 1 Harting 21 03 281 1405 HARAX M12-L TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00 Page 59 of 76... -
Seite 60: Switching On The Supply Voltage
This applies for the SAFE-OPERATIONAL and OPERATIONAL states. Mailbox access is generally triggered by SDO requests. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 60 of 76... -
Seite 61: Commissioning
No error, measuring system ready for operation Measuring system or hardware error For appropriate measures in case of error see chapter "Optical displays" page 75. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016... -
Seite 62: Communication Specific Objects
“Status” (page 64) is set in the next cycle again. 8-15 unused Table 1: RxPDO TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 62 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 63: Transmit Process Data Object 1A00H (Txpdo)
2 About this input byte the momentary intensity in [%] of the laser beam is transmitted. Default value: 100 % = 0x64. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 64: Speed
TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 64 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 65: Manufacturer And Profile Specific Objects (Cia Ds-406)
Bit 0 = 0: Parameter are not saved Value Bit 0 = 1: Parameter are saved Default TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 66: Object 2001H: Preset Clear
Max. value 65 535 Default 100 dec. = 1 mm TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 66 of 76 TR - ELE - BA - DGB - 0024 - 00 01/21/2016... -
Seite 67: Object 2003H: Failure Auto Quit
Bit 0 = 0: 10 mm/s, corresponds 0.01 m/s Value Bit 0 = 1: 1 mm/s, corresponds 0.001 m/s Default TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 68: Object 2005H: Function Ext. Input
Failure-quit: Switching input is used as error acknowledgement. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 68 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 69: Object 2006H: Function Ext. Output
The switching output is set, if the plausibility of the measured value cannot be guaranteed. E.g. this is the case at a position jump if a second reflection foil is held into the laser beam. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016... -
Seite 70: Object 2007H: Failure Value
Bit 0 = 0: Execution with rising slope Value Bit 0 = 1: Execution with falling slope Default TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 70 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 71: Object 200Ah: Laser Diode Switch (On/Off)
Bit 0 = 0: Position values increasing Value Bit 0 = 1: Position values decreasing Default TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 72: Object 6003H: Preset Value
Byte 3 to 2 to 2 to 2 to 2 TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 72 of 76 TR - ELE - BA - DGB - 0024 - 00 01/21/2016... -
Seite 73: Object 6005H: Resolution
* see “Object 2002h: Free Resolution” on page 66 So that this Object is saved permanently, “Object 2000h: Accept parameters” must be executed. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 74: Read-Out The Supported Objects Of The Measuring System
● Click the Advanced button ● Select radio button Online... ● --> All Objects TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 74 of 76 TR - ELE - BA - DGB - 0024 - 00... -
Seite 75: Error Causes And Remedies
If the error is existing furthermore, hardware error the device must be replaced. TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany 01/21/2016 TR - ELE - BA - DGB - 0024 - 00... -
Seite 76: Other Faults
Only after this time the regular operating should be taken up. Table 4: Status bits TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany Page 76 of 76 TR - ELE - BA - DGB - 0024 - 00...
