Selecting information
Fig. 131: Selecting information
Fig. 132: "Hand switch" menu

7.7 "Store memory positions" menu

Selecting a menu
Fig. 133: Selecting a menu
20.08.2021
2.
Prerequisites:
n The drive position being saved has been assumed.
n The short menu for the hand switch is displayed
1.
Control unit RK MultiControl II duo/RK MultiControl II quadro
Select one of the following menus depending on which infor-
mation you wish to display (Fig. 131):
Menu Information
Hand Software and hardware version of the hand
switch switch
Drive Connected (drive(s) (e.g. Multilift II))
The info menu "Control" contains the following
menu items:
Control
® "Configuration"
unit
® "Software and hardware version"
® "Serial/OC-number"
Manufac- Address of RK Rose+Krieger GmbH
turer
QR code
for installa-
You can use a QR code scanner to download
tion
these instructions.
instruc-
tions
ð The information on the selected menu (in this case: hand
switch, Fig. 132) is displayed.
The function allows you to save the positions of the
drives (memory positions).
2 memory positions per user can be saved.
Select the "Store memory positions" menu (
Operating the hand switch with 6 function buttons
Store memory positions menu
Ä Page 170.
).
