6

Operating the hand switch with 2 function buttons

Improper operation

6.1 Overview

Operating interface
Fig. 29: Hand switch operating inter-
face
20.08.2021
1 [Down] button
2 [Up] button
The drives connected to the control unit are moved by pressing the
buttons
Control unit RK MultiControl II duo/RK MultiControl II quadro

Operating the hand switch with 2 function buttons

WARNING!
Risk of injury as a result of improperly per-
formed operating actions!
Improper operation of the hand switch and
improper movement of the drives connected to the
control unit can cause serious injuries and consid-
erable material damage.
– Follow and adhere to all the safety instructions
and instructions for actions indicated in these
instructions.
– Only use the control units and the hand
switches in perfect condition.
– Before each commissioning procedure, make
sure that there are no persons or objects in the
danger area of the drives.
– Only actuate hand switches if you have visual
contact with the drives.
– If the drives are not stopping, disconnect the
control unit mains plug.
– Have all operating tasks carried out by qualified
staff only.
.
Overview
