Operating the hand switch with 6 function buttons
Control menu > Commissioning menu
7.5.1.2.3 Deactivating drive group management
Selecting a menu
Fig. 80: Deactivating drive group man-
agement
7.5.1.2.4 Moving drive groups
Moving drive groups individually
Fig. 81: Drive group management
activated
Fig. 82: Moving the drive group
188
Prerequisites:
n Drive group management is currently activated.
n The main menu for the hand switch is displayed
Prerequisite:
n Drive group management is currently activated.
1.
2.
Control unit RK MultiControl II duo/RK MultiControl II quadro
Select the menu via "Control" ® "Commissioning" ®
"Deactivate drive group management" .
ð Drive group management has been deactivated.
Press the button (
tive drive group.
ð The selected drive group is currently activated and is dis-
played inversely (
Press the buttons to move the selected drive group (in
this case: ).
Ä Page 169.
) or button ( ) for the respec-
or ).
