Operating the hand switch with 6 function buttons
Control menu > Parameter menu
Fig. 124: Selecting a menu
Changing parameters
Fig. 125: Selecting parameters
Fig. 126: Entering a value (example)
Table of parameters
No. Parameter
1 Stroke display, input of the height for display when extended
Basic height, input of the height for display when retracted: 0 -%
2
Unit, input of the unit for the display:
3
0 -%; 1 - cm; 2 - mm; 3 - inches
Safety edge: 0 - deactivate; 1 - activate
4
External stop input: 0 - deactivate; 1 - activate
5
208
Prerequisite:
n The main menu for the hand switch is displayed
1.
2.
3.
Control unit RK MultiControl II duo/RK MultiControl II quadro
Select the menu via "Control" ® "Parameter" ® "Change
parameter" (Fig. 124).
ð The "Change parameter" menu (Fig. 123) is displayed.
Select the parameter as per the table of parameters
208.
Set the parameter (Fig. 126).
ð The parameter has been set.
Ä Page 169.
Ä Page
Default
Min. Max.
(MLII)
1 1 9999
0
0 9999
0 0 3
0 0 1
0 0 1
20.08.2021
