Operating the hand switch with 6 function buttons
Control menu > Stroke limit menu
Selecting a menu
Fig. 90: Selecting a menu
Activating stroke limitation
Fig. 91: Activating stroke limitation
Deactivating stroke limitation
Fig. 92: Deactivating stroke limitation
7.5.3.2

Set lower stroke limit menu

192
Prerequisites:
n The drives are in the desired position which is used as the final
position.
n The main menu for the hand switch is displayed
1.
2.
3.
Control unit RK MultiControl II duo/RK MultiControl II quadro
Select the menu via "Control" ® "Stroke limit" ® "Set upper
stroke limit" (Fig. 90).
Select "Set upper stroke limit" (Fig. 91).
ð The current position of the drives is applied as the upper
final position.
Select "Deactivate upper stroke limit" (Fig. 92).
ð The upper final position determined or set during the initi-
alization run is applied.
The lower stroke limit can be set either during the
initialization run or later using the "Set lower stroke
limit menu" menu.
Ä Page 169.
20.08.2021
