7.5.7.3

"SERVICE DRIVE" menu

Advanced password
Selecting the "SERVICE DRIVE"
menu
Fig. 119: Selecting a menu
Fig. 120: "SERVICE DRIVE" menu
Carrying out an initialization run
7.5.7.4

"Options register display" menu

20.08.2021
Prerequisite:
n The main menu for the hand switch is displayed
1.
2.
Control unit RK MultiControl II duo/RK MultiControl II quadro
The menu is only displayed if the advanced pass-
word has been set
The advanced password is available on request
from RK Rose+Krieger GmbH.
The function allows you to move individual or mul-
tiple drives even in the event of an error for trou-
bleshooting purposes.
Select the menu via "Control" ® "Service" ® "SERVICE
DRIVE" (Fig. 119).
ð The "SERVICE DRIVE" menu (Fig. 120) is displayed.
In the "SERVICE DRIVE" menu
(Fig. 120) one or multiple drives ( "M1"
"M4" ) can be selected and their positions
can be displayed.
"PWM" (pulse width modulation) is used
to set the speed of the selected drive and
the selected drive is moved using "run" .
Carry out an initialization run
This function is only available with the premium
customised version and is used to display acti-
vated options for control units with special func-
tions.
Operating the hand switch with 6 function buttons
Control menu > Service menu
Ä Page 179.
Ä Page 169.
Ä Page 180.
-
