Selecting the "Collision detection"
menu
Fig. 102: Selecting a menu
Selecting the direction of travel
Fig. 103: Selecting the direction of
travel
Activating collision detection (SPP)
Fig. 104: Activating the collision
detection menu
20.08.2021
Prerequisite:
n The main menu for the hand switch is displayed
1.
2.
3.
Control unit RK MultiControl II duo/RK MultiControl II quadro
Select the menu via "Control" ® "Stop functions" ®
"Collision detection" (Fig. 102).
Select the direction of travel "Extend" or "Retract" (in this
case: "Retract" , Fig. 103).
Set the sensitivity of collision detection for the selected direc-
tion of travel (in this case: "Sensitivity high" , Fig. 104):
n High:
Detection threshold 50 mA (default value for Multilift II)
n Medium:
Detection threshold 150 mA (default value for Multilift II)
Low:
n
Detection threshold 250 mA (default value for Multilift II)
n User defined:
Adjustable detection threshold from 0 - 4000 mA
When drive group management is activated,
set collision detection (SPP) separately for
each drive group.
ð Collision detection has been activated.
Operating the hand switch with 6 function buttons
Control menu > Stop functions menu
Ä Page 169.
