Selecting a menu
Fig. 109: Selecting a menu

7.5.6 "Memory positions for IO Interface" menu

7.5.6.1

Storing memory positions

Selecting a menu
Fig. 110: Selecting a menu
20.08.2021
Prerequisites:
n The synchronisation bus is connected
n The bus system has been activated
n The main menu for the hand switch is displayed
Prerequisites:
n The drive position being saved has been assumed.
n The main menu for the hand switch is displayed
1.
Control unit RK MultiControl II duo/RK MultiControl II quadro
Control menu > Memory positions for IO Interface menu
Call up the menu via "Control" ® "Sync-BUS settings" ®
"Deactivate BUS connection" (Fig. 109).
ð The bus system is deactivated.
This function can be used to configure and assume
the seven IO interface memory positions.
To save a memory position, it first has to be
assumed using the IO interface module
139.
Select the menu via "Control" ® " Memory positions for IO
Interface" ® "Store memory positions" (Fig. 110).
Operating the hand switch with 6 function buttons
Ä Page 158.
Ä Page 199.
Ä Page 169.
Ä Page
Ä Page 169.
201
