3.4 Drives

Incompatible drives
Compatible drives
Display/ Drive
code
10 Multilift I/Multilift synchro
11 Multilift II
12 Multilift II Telescope
13 Multilift II Impact
20 RK Slimlift
21 RK Slimlift EM
LZ60P
30
LZ60S
LZ P drive unit
35
Drive unit LZ S
44 RK Powerlift M
20.08.2021
The following RK Rose+Krieger GmbH drives can be connected to
the control unit:
Nominal load
[N]
1000
3000
1000
3000
1000
3000
1000
3000
1000
4000
1000
1000
2000
3000
4000
1500
3000
4 Nm
5 Nm
1500
3000
Control unit RK MultiControl II duo/RK MultiControl II quadro
NOTICE!
Material damage caused by using an incompa-
tible drive!
– Only use the RK Rose+Krieger GmbH drives
listed in the table.
Resolution
[inc/mm]
2.0000
4.000
26.000
52.000
25.333
52.000
26.000
52.000
10.000
40.000
25.333
8.250
16.500
33.000
58.667
10.000
40.000
132 inc/r
160 inc/r
26.667
40.000
Set-up and function
Drives
Speed
[inc/s] [mm/s]
26 13.00
26 6.50
360 13.85
360 6.92
360 14.21
360 6.92
360 13.85
360 6.92
195 19.50
195 4.88
390 15.40
185 22.42
185 11.21
185 5.61
185 3.15
185 18.5
185 4.63
185 1.4015 rps
185 1.1555 rps
278 10.43
278 6.95
141
