Installation Instructions
(HA) x 3
1
Figure 13
3. Add one remaining M4 x 10mm Phillips pan head screw
(HA) through the projector arm and into the projector. (See
Figure 14)
4. Tighten all four fasteners.
(HA)
3
Figure 14
5. Loosen two button head screws on top of short throw
projector arm (A). (See Figure 15)
6
9
Figure 15
8
5
(A)
(Projector not shown)
6. Slightly loosen four hex screws between projector arm and
projector mount. (See Figure 15)
7. Slide projector along short throw projector arm until edge of
projector mount lines up with screen diagonal listed on
projector arm label. (See Figure 17)
IMPORTANT ! :
For installations other than the dedicated
screen/white board:
1. Measure the depth of the screen/white board (A),
and add that measurement to the throw distance
indicated on the install template. (See Figure 16) or
(See Figure 2).
2. Move projector closer to end of projector arm by that
depth measurement (A).
2
Move projector
mount closer to
end of arm by
distance of
A
Figure 16
8. Tighten two button head screws on top of short throw
projector arm (A) to lock projector in place. (See Figure 15)
9. Tighten four hex screws between projector arm and
projector mount. (See Figure 15)
Projector arm labels
(View from below)
Figure 17
MSP-DCCUST2
THROW DISTANCE
wall
Example white
1
board depth
Edge of projector mount
(with arrow cut-outs) should
line up with screen
diagonal on labels.
7
Line up edge
of projector
mount with
screen
diagonal
on label
A
