- Seite 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation FUSION MEDIUM HEIGHT ADJUST FLAT PANEL MOUNTS MSM/MTM Series...
-
Seite 2: Installation Instructions
WARNING: Failure to provide adequate structural strength for this component can result in serious personal injury or Chief® is a registered trademark of Milestone AV Technologies. damage to equipment! It is the installer’s responsibility to All rights reserved. make sure the structure to which this component is attached can support five times the combined weight of all equipment. - Seite 3 Installation Instructions MSM/MTM Series DIMENSIONS 25.60 [650] MAX HORIZONTAL SPACING 18.79 477.4 [12.7] 16.00 UP/DOWN 406.4 ADJUSTMENT EACH SIDE 7.63 193.7 1.52 38.5 7.53 191.2 16.50 15.75 419.1 1.00 13.53 6.00 15.10 25.4 343.7 152.4 383.4 1.96 1.75 VERTICAL 49.8 44.5 SPACING RAILS SLIDE...
- Seite 4 Installation Instructions MSM/MTM Series LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación Perforar...
-
Seite 5: Tools Required For Installation
MSM/MTM Series Installation Instructions TOOLS REQUIRED FOR INSTALLATION 7/32" (5.5mm) Wood Stud 5/16" (7.9mm) Concrete PARTS B (1) C (1) A (1) D (1) [Included with MSM6XXX/MTM6XXX E (1) Models Only] (MSM Only) Custom J (1) [Used on MSMU/MTMU Models Only] MSM6XXX/ MTM6XXX F (1) -
Seite 6: Locate Mounting Site
MSM/MTM Series Installation Instructions INSTALLATION Measure up 7-1/2" from the center point to mark location of the upper mounting slots. The MTM and MSM have been designed to be mounted directly Using a level, mark the wall on each stud to attach the onto either a wood stud or concrete wall. - Seite 7 Installation Instructions MSM/MTM Series Drill 7/32" pilot holes at markings for lower mounting holes. (See Figure 3) WARNING: EXPLOSION AND FIRE HAZARD! CUTTING 10. Use two 5/16 x 2-1/2" lag bolts (K3) and two 5/16" flat OR DRILLING INTO GAS PLUMBING CAN CAUSE DEATH washers (K2) [one lag bolt and washer for single stud OR SERIOUS PERSONAL INJURY! ALWAYS make certain installation] to attach the mount to the wall through the lower...
- Seite 8 MSM/MTM Series Installation Instructions Mark the attachment points for the lower mounting slots. (See Figure 4) Mounting Drill one pilot hole at each marking for lower mounting Holes holes. (See Figure 4) 10. Install an anchor (K1) into each pilot hole using a hammer. 11.
- Seite 9 Installation Instructions MSM/MTM Series Center Line (CL) Pullstraps NEVER place both interface brackets to one side of the wall mount center line (CL)! Knobs to outside of brackets Figure 7 If necessary, the tilt interface bracket knobs may be switched to allow the interface brackets to be reversed. (See Figure 7) a.
- Seite 10 MSM/MTM Series Installation Instructions Raises screen Lowers screen Hook (Screen not shown for clarity) Figure 10 Locking Mount (Optional) Add optional security bracket (F or G) to the mount. (See Figure 11) Add padlock (not included) to complete security. Pullstraps (Screen not shown for clarity) Figure 9 Hang top hook of interface brackets onto the top bar of the...
- Seite 11 Installation Instructions MSM/MTM Series...
- Seite 12 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 F +31 (0)40 2668615 Chief Manufacturing, a products division Asia Pacific A Room 24F, Block D, Lily YinDu International Building of Milestone AV Technologies LuoGang, BuJi Town, Shenzhen, CHINA.
