2. Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer,
we wish you much pleasure and success in working
with your new device.
Note:
In accordance with the applicable product liability
laws, the manufacturer of this device assumes no
liability for damage to the device or caused by the
device arising from:
• Improper handling,
• Failure to comply with the operating manual,
• Repairs carried out by third parties, unauthorised
specialists,
• Installing and replacing non-original spare parts,
• Application other than specified.
Note:
Read the whole text of the operating manual before
assembly and commissioning.
This operating manual should help you to familiarise
yourself with your device and to use it for its intended
purpose.
The operating manual includes important instructions
for safe, proper and economic operation of the de-
vice, for avoiding danger, for minimising repair costs
and downtimes, and for increasing the reliability and
extending the service life of the device.
In addition to the safety instructions in this operating
manual, you must also observe the regulations appli-
cable to the operation of the device in your country.
Keep the operating manual with the device at all times
and store it in a plastic cover to protect it from dirt and
moisture. They must be read and carefully observed
by all operating personnel before starting the work.
The device may only be used by personnel who have
been trained to use it and who have been instructed
with respect to the associated hazards. The required
minimum age must be observed.
In addition to the safety instructions in this operating
manual and the separate regulations of your coun-
try, the generally recognised technical rules relating
to the operation of such machines must also be ob-
served.
We accept no liability for accidents or damage that
occur due to a failure to observe this manual and the
safety instructions.
3. Device description (Fig. A - O)
1.
Front hand guard
2.
Front handle
3.
Air filter cover
4.
Start pull cord
5.
Lock for the air filter cover
6.
On/off switch
7.
Fuel pump "primer"
8.
Cold start lever (choke)
9.
Throttle interlock
10. Throttle
11. Rear handle
12. Rear hand guard
13. Fuel tank cap
14. Chain oil fuel cap
15. Claw stop (pre-assembled)
16. Guide rail
17. Saw chain
18. Bench grinder aid
19. Oil adjustment screw
20. Fixing nuts
21. Chain tensioning screw
22. Chain cover
23. Chain tensioning pin
24. Chain catcher
25. Hole for the chain tensioning pin
26. Chain wheel
27. Guide rail cover
28. Screwdriver
29. 4 mm Allen key
30. Mixing container
31. Spark plug wrench / slotted screwdriver
32. Round saw chain file
33. Air filter
34. Spark plug connector
4. Scope of delivery
• Chainsaw (1x)
• Saw chain (1x)
• Guide rail (1x)
• Guide rail base (1x)
• Spark plug wrench (1x)
• Allen key, 4 mm (1x)
• Fuel mixing container (1x)
• Round saw chain file (1x)
• Screwdriver (1x)
• Original Operating Manual (1x)
5. Proper use
The chainsaw may only be used for cutting wood out-
doors. The chainsaw must not be used for any other
purpose.
Do not use the chainsaw for work for which it is not
intended. Example: Do not use the electric chainsaw
to saw metal, plastic, brickwork or building materials
other than wood.
