CHOKE
10x
ON
30 | GB
Filling port for saw chain oil.
Pushed in - choke deactivated
Pulled out - choke activated
Fuel pump primer
Set screws for carburettor:
L
Low engine speed
H
High engine speed
T
Idle speed
Adjusting the chain brake:
White arrow: Chain brake inactive.
Black arrow: Chain brake active.
Installation direction of the saw chain.
Guaranteed sound power level of the device.
Attention! Hot surface.
On/off switch - "ON"
On/off switch - "STOP"
Weight
Mixing ratio
Avoid contact with the rail tip.
Fire prohibited.
www.scheppach.com
