NeoFlow pressure reducing valve
1.3

Technical data

1.3.1 Specifications
Specifications
Pressure ratings and perfor-
mance
Materials
Flanges
*With medium temperature ≤ 20°C; >20°C on request
1.3.2 Kv 100 values
DN
(mm)
DN50
DN80
DN100
DN150
6
Maximum inlet pressure P1
Maximum outlet pressure P2
Outlet pressure range
Minimal pressure difference P1– P2
Casing
Piston
Elastomers
Fittings
Pilot control
Inch
(")
2
-
4
6
16 bar*
16 bar**
0.1 to 16 bar**
0.2 bar***
POM-C
POM-C
EPDM
Stainless Steel / Brass
Stainless steel, POM-C, PTFE
Metric: PN10/16 Imperial: ANSI 150
**Depending on the pilot valve type
Kv 100
(m /h)
3
30
73
130
266
***Dependent on flow and size
Kv 100
(l/min)
500
1217
2167
4433
Instruction manual
Cv 100
(US gal./min)
35
84
150
307
