Control Block; Pilot Valve - GF NeoFlow Betriebsanleitung

Instruction manual
12.3

Control block

2
3
4
5
12.4

Pilot valve

1
5
4
3
2
No. Designation
1 Adjusting screw pilot valve (AS)
2 Locking nut
3 Indication disc
4 Spring case
5 Screws (8) for the spring case
6 Upper Spring Guide
7 Pilot spring
8 Locknut
9 Internal spring guide
10 Protective pane
11 Diaphragm support
12 Diaphragm
13 Diaphragm bolt
14 Diaphragm casing
15 Assembly pin
16 O-ring pilot body
17 Pilot body
18 Sticker
19 Actuator pin
20 Control cylinder
21 Control spring
22 Pilot control sealing plug
1
9
8
7
10 11
6
No. Designation
1 Control block main body
2 Label
3 Filter
4 O-ring sealing plug
5 Filter sealing plug
16
13
14 15
12
NeoFlow pressure reducing valve
22
21
18
19 20
17
