Instruction manual
17
18
19
20
21
22
10. To clean the pilot valve, unscrew the sealing plug (22), remove the control spring (21) and control cylinder (20) with the actuator
pin (19) and blow out using compressed air.
11. Clean the sealing plug (22) and reassemble, glue the sealing plug (22) with bolt retention. Notice: After opening, the threads must
be thoroughly cleaned and coated with sealing drinking water-safe thread glue during assembly, e.g. Weiconlock AN 302-43,
Loctite 577. Observe the instructions of the thread glue manufacturer.
NeoFlow pressure reducing valve
25
