en 78 | ROLL R6 M | Faults
Faults Causes
20 1. Pedal pressed during measurement
2. Irregular rotational speed of motor
3. Wheel speed below minimum value
21 The PCB has detected an excessively high wheel speed
with the wheel guard open (shaft rotating at high speed
although the machine has not been started): Power
supply unit is deactivated
22 Irregular measurement sensor signals
29 ATTENTION: One electronic vernier caliper not in rest
position.
30 Angular width gauge deactivated.
31 Pedal being pressed. Deactivation takes place.
32 Pedal has been pressed.
33 Incorrect operating system
34 Restart the system.
38 Idioms text missing.
39 WINCE firmware version incorrect, for the language
selected.
40 Emergency stop.
41 The width gauge must be calibrated.
+ No power supply
Wheel can
+ No compressed air supply
no longer be
+ Electrical fault
removed
|
1 695 600 694 2016-09-28
Remedy
1. Do not press pedal whilst motor is in operation.
2. Make sure the ROLL R6 M is not subjected to any
impact during measurement.
3. Check mains voltage (probably too low).
1. Switch off the ROLL R6 M .
2. Lower the wheel guard, switch the ROLL R6 M on
again without moving the wheel.
3. If the error message persists, contact customer
service.
1. Check that the light barrier PCB is protected
against light and provide a cover if necessary.
2. Check and if necessary replace the light barrier
PCB.
3. Check and if necessary replace the display PCB.
1. Set electronic vernier caliper to rest position.
2. Repeat calibration of electronic vernier caliper.
Perform calibration prior to reactivation.
1. Avoid pressing the pedal during measuring cycle;
If the error message persists, contact customer
service.
1. Avoid pressing the pedal during measuring cycle;
If the error message persists, contact customer
service.
Use a different PCB.
If the error message persists, contact customer
service.
The language selected will be replaced by English.
Repeat the measuring cycle.
Calibrate the width gauge.
1. Check whether power and compressed air (be-
tween 3.5 and 4 bar) are being applied
2. Switch off and on again
3. Heed instructions in Section "Removing the
wheel".
If the error message persists, contact customer
service.
