en 46 | ROLL R6 M | Symbols used
1.

Symbols used

1.1

In the documentation

1.1.1 Warning notices - Structure and meaning
Warning notices warn of dangers to the user or people
in the vicinity. Warning notices also indicate the
consequences of the hazard as well as preventive action.
Warning notices have the following structure:
Warning
KEY WORD – Nature and source of hazard!
symbol
Consequences of hazard in the event of
failure to observe action and information
given.
€
Hazard prevention action and information.
The key word indicates the likelihood of occurrence and
the severity of the hazard in the event of non-observance:
Key word Probability of
occurrence
DANGER Immediate impending
danger
WARNING Possible impending
danger
CAUTION
Possible dangerous
situation
1.1.2 Symbols in this documentation
Symbol Designation Explanation
Attention Warns about possible property damage.
!
Information Practical hints and other
i
useful information.
1. Multi-step Instruction consisting of several steps.
2. operation
One-step Instruction consisting of one step.
e
operation
Intermediate An instruction produces a visible
«
result intermediate result.
Final result There is a visible final result on
"
completion of the instruction.
|
1 695 600 694 2016-09-28
Severity of danger if
instructions not observed
Death or severe injury
Death or severe injury
Minor injury
1.2

On the product

!
Observe all warning notices on products and ensure
they remain legible.
1.2.1 Product information
Back of machine
The following information can be found here:
Machine model, 10-digit ID number, voltage (V),
frequency (Hz), connected load (kW), amperage (A),
max. supply pressure (kPa), degree of protection (IP),
year of manufacture, CE mark, EAC identifier, serial
number of the machine, barcode.
Disposal
Dispose of used electrical and electronic
devices, including cables, accessories and
batteries, separately from household waste.
EAC mark
€
Confirms the suitability of the machine for
Russia.
Direction of wheel rotation
Wheel must turn in direction indicated.
(see chapter "Checking the direction of
rotation")
Power supply voltage
€
Follow the indications given on the plate.
Balancing Start-Stop
€
Located on the wheel protection indicates the
direction to activate/stop the flange rotation.
OMCN spa
