8.

Program structure

8.1

Wheel balancing

To proceed, confirm by pressing <I>.
Selection of user 1, 2 or 3. The last settings and rim data
selected are assigned to the current user and stored.
Selection of type of vehicle (passenger car or
motorcycle); the type of vehicle selected is displayed in
the status bar.
Call-up of the "Enter rim data" menu.
Selection of balancing program; 11 passenger car
programs, 5 motorcycle programs; the program selected
is displayed in the status bar.
Starts measurement.
Ends measurement.
Display of the exact, non-rounded unbalance measured
value.
Selection of number of spokes.
The weight can be distributed behind the spokes after
measuring the unbalance.
Call-up of the "Unbalance minimization" program
(refer to Section 10).
Press < I > to return to the previous page.
OMCN spa
Program structure | ROLL R6 M | 61
8.2 Settings and service
Call-up of service menu (customer service only)
Call-up of calibration menu
Press < I > to return to the previous page.
Settings
User-defined settings
i
The following symbols are used in the selection
menus:
Automatic transfer (e.g. time)
Manual transfer (e.g. via pedal)
Function deactivated
8.2.1 Calibration
Calibration of ROLL R6 M
Flange calibration.
Press < I > to return to the previous page.
Electronic Vernier caliper calibration.
en
|
