OMCN ROLL R6 Betriebsanleitung Seite 67

9.3.3 Alu2 balancing program
1. Place the electronic calliper gauge on the distance
and diameter of the rim in correspondence of the
edge of the rim and keep it in this position for one
second.
i
An acoustic signal sounds to indicate that the
position has been registered.
2. Subsequently, without bringing the calliper gauge to
stand-by position, place it in correspondence of the
first balancing plane and keep it in that position for
one second.
i
An acoustic signal sounds to indicate that the
position has been registered.
3. Next, without bringing the electronic calliper gauge
to home position, position it in correspondence
of the second balancing plane and keep it in this
position for one second.
OMCN spa
Balancing a wheel | ROLL R6 M | 67
i
The procedure for entering data for internal points is
completed; move the slide gauge back to its position
at rest.
!
The angular width gauge is not required for the Alu2,
Alu3/Pax2 balancing program: all the measuring
points are detected by the electronic calliper gauge.
en
|
