14. Technical data

14.1 ROLL R6 M
Function
Balancing speed
Resolution
Power supply
Protection class
14.2 Temperatures and operating range
Function
Operating temperature
Storage temperature
Temperature gradient
Relative humidity in operation
Relative humidity gradient
Installation height
Transportation height
14.3

Operating range

Function
Settable rim width
Measurable rim width
Settable rim diameter
Measurable rim diameter
Maximum wheel weight
Maximum wheel diameter
Power input
Maximum width of wheel
Average cycle time
14.4

Dimensions and weights

Function
ROLL R6 M (H x W x D) max.
Net weight
OMCN spa
Specification
208 U/min 50 Hz /
250 U/min 60 Hz
1/5 g (0.01/0.25 oz)
110V /1 ph/ 50-60 Hz
230V /1 ph/ 50-60 Hz
230V/1 ph/50 Hz
IP 22
Specification
+5 ° C \ +40 ° C
-20° C \ + 60° C
20° C
<75 % \ max 90 % (25 ° C, 24 h)
10 %
-200 m. \ 2.200 m.
-200 m. \ 12.000 m.
min – max
1" - 24"
1" - 20"
6" - 40"
10" - 27"
70 kg
1200 mm
0,7 kW
500 mm
8 sec
Specification
1830x1260x1270 mm
131 kg
