9.2 Manual selection of the balancing
program
i
Static balancing is recommended for wheels with
a width of less than 3.5": In this case only the rim
diameter value is entered.
i
The values for distance and width of the rim can be
set arbitrarily in inches or mm.
1. Check the currently selected type of vehicle
(passenger car or motorcycle) in the status bar, alter
if necessary and confirm with <I>.
2. Check the currently selected balancing program in the
status bar, alter if necessary and confirm with <I>.
i
The current settings for attachment of the adhesive
weight only apply to PAX2 and ALU2 (inside and
outside) and ALU3 (outside). Otherwise, the
adhesive and clip-on weights are always to be
attached in the 12 o'clock position.
i
The balancing plane is the plane to application of
the counterbalance or, simply, balancing weight.
i
By convention, the Plane/internal weight is that
closest to the object holder tray; vice-versa, the
Plane/external weight is always the farthest from the
object holder tray.
OMCN spa
Balancing a wheel | ROLL R6 M | 65
9.3 Automatic selection of the balancing
program
The balancing program is selected automatically for the
Standard, ALU2 and ALU3 programs
i
You can select one of the 3 programs according to
the number of points detected on the rim using the
electronic calliper gauge.
i
The position of the second and third measuring
points depend on the selected balancing program.
1. Confirm access to the balancing menu on the home
page by pressing <I.
9.3.1 Standard balancing program
1. Place the electronic calliper gauge on the distance
and diameter of the rim in correspondence of the
first balancing plane (edge of the rim) and keep it in
this position for one second.
