BONFIGLIOLI Active Cube Betriebsanleitung Seite 63

Motoranschl. ACU 201 (4,0 bis 9,2 kW) und 401 (5,5 bis 15,0 kW)
Betriebsanleitung ACU
06/13
U V W
U
Dreieckschaltung Sternschaltung
4.0 kW ... 9.2 kW
6qmm / RM7,5
0.2 ... 6 mm
AWG 24 ... 10
0.2 ... 6 mm
AWG 24 ... 10
0.25 ... 4 mm
AWG 22 ... 12
0.25 ... 4 mm
AWG 22 ... 16
Anschluss Bremswiderstand mit Temperaturschalter
4.0 kW ... 9.2 kW
6qmm / RM7,5
0.2 ... 6 mm
AWG 24 ... 10
0.2 ... 6 mm
AWG 24 ... 10
0.25 ... 4 mm
AWG 22 ... 12
0.25 ... 4 mm
AWG 22 ... 16
X2
U
V W
X2
M
3~
V W
11.0 kW ... 15.0 kW
16qmm / RM10+15
2
2
2
2
X2
U V W
X2
11.0 kW ... 15.0 kW
16qmm / RM10+15
2
2
2
2
Rb1 Rb2
2
0.2 ... 16 mm
AWG 24 ... 6
2
0.2 ... 16 mm
AWG 24 ... 6
2
0.25 ... 10 mm
AWG 22 ... 8
2
0.25 ... 10 mm
AWG 22 ... 8
Rb1 Rb2
R
b
Rb1 Rb2
T1 T2
2
0.2 ... 16 mm
AWG 24 ... 6
2
0.2 ... 16 mm
AWG 24 ... 6
2
0.25 ... 10 mm
AWG 22 ... 8
2
0.25 ... 10 mm
AWG 22 ... 8
63
