Input coupling
Input impedance
Probe attenuation factor
Max. input voltage
Input
Bandwidth limit
Channel isolation
Time
channel (typical)
Sampling rate range
Interpolation
Horizontal
System
Record length
Scanning speed（S/div）
Sampling rate / relay time
accuracy
Horizontal
Interval ( △ T)accuracy
System
(DC ~ 100 MHz)
A/D converter
Sensitivity
Displacement
Analog bandwidth
Vertical system
Single bandwidth
Low Frequency
Rise time
DC accuracy
DC accuracy (average)
DC, AC, Ground
1 M ± 2 %，in parallel with 15 pF ± 5 pF
1X,10X, 100X, 1000X
400 V (PK-PK) (DC + AC PK-PK)
20 MHz, 100 MHz
50 Hz: 100 : 1
10 MHz: 40 : 1
delay
between
150 ps
* 1 Sa/s ~
* 1 Sa/s ~
(sin x)/x
2 M points on each channel
* 2 ns/div ~ 100 s/div, step by 1 ~ 2 ~ 5 (P 1190)
* 1 ns/div ~ 100 s/div, step by 1 ~ 2 ~ 5 (P 1230)
± 100 ppm
Single : ± (1 interval time+100 ppm×reading+0.6 ns);
Average > 16 : ± (1 interval time + 100 ppm×reading+
0.4 ns)
8 bits resolution (2 Channels simultaneously)
2 mV/div ~ 10 V/div (at BNC)
± 1 V (2 mV ~ 50 mV), ± 10 V (100 mV ~ 1 V),
± 100 V(2 V ~ 10 V)
100 MHz (P 1190)
200 MHz (P 1230)
Full bandwidth
≥ 5 Hz (at input, AC coupling, -3dB)
* ≤ 3.5 ns (at input, Typical) (P 1190)
* ≤ 1.75 ns (at input, Typical) (P 1230)
± 3 %
Average﹥16: ± (3 % rdg + 0.05 div) for △ V
