Warning: When use BC(battery charge) as power supply, to avoid fire or electrical shock if a test
tool input is connected to more 42V peak (30Vrms) or on circuits of more than 4800VA:
*
Only use accessory insulated voltage probes, test lead
*
Before use, inspect oscilloscope probes, accessories for mechanical damage and replace when damage.
*
Remove all probes, test leads and accessories that are not in use.
*
Remove computer data line
*
Do not apply input voltages above the rating of the instrument Use caution when using 1:1 test leads
because the probe tip voltage will be directly transmitted to the oscilloscope.
*
Do not use exposed metal BNC or banana plug connectors
*
Do not insert metal objects into connectors.
3. General Characteristics of the PeakTech
3.1. Digital Storage Oscilloscope
* With the bandwidth of 100 MHz (P 1190) / 200 MHz (P 1230)
* Sample Rate 500 MSa/s (P 1190) / 1 GSa/s (P 1230)
* Record length for each channel of 6.000 (P 1190) / 2.000.000 points (P 1230) for oscilloscope use
* Record length of 4.000.000 points for Logic Analyzer use (P 1190/1230)
* Reading-out with the cursor
* Twenty automatic measurement functions
* Autoscale function
* Color liquid crystal display of high resolution and high contrast with adjustable back light
* Storage and call-out of waveforms
* Automatic setting function provided capable of fast setting
* Multiple-waveform calculation function
* Built-in FFT function
* Implementation of detecting the average and peak values of the waveform
* Digital real-time oscilloscope
* Edge, video; pulse, slope and alternate triggering function
* USB communication ports
* Different continuous displaying time
* Multiple Language User Interface
3.2. Logic Analyzer
* With the bandwidth of 66MHz;
* 16 input channel;
* 400 MSa/s max sampling rates for each channel;
* 4 M max Storage for each channel;
* Plenty of trigger Mode;
* Convenient data measurement & data search;
* Freely setting of all kinds of threshold level;
®
1190 / 1230 Oscilloscopes
-113-
