2. Search specified value in BUS
Searching BUS menu as below:
Function
BUS
BUS0~BUS3
0x0000~0xffff
Code type
(HEX)
0~65535 (DEC)
Previous
Next
For example, follow up below steps to search the data of 0x18 values in BUS0
1.
Press "2(SEARCH)" and menu appears.
2.
Press "F1" till target display as "BUS".
3.
Press "F2" till BUS SEL as "BUS0".
4.
Press "F3" and choose "Code Type ", value under displayed with red background and green digital
indicator in the panel is on. Then insert the value of "18" by digital key in the panel to get start.
5.
Press "F3" again and red background for value under code is disappeared and value setting finished.
Repeat operation of steps D. E if need to modify the value.
6.
Press "F4" and choose "Previous" to searching the matched value prior to current cursor. Cursor will stop
in this value if it has and info window show "Got the target" and if it hasn't it will show "Search failed".
7.
Press "F5" and choose " Next" to searching the matched value after current cursor.
Fig. 97 Search trigger position
Setting
Instruction
Choose searching BUS
Can be set discretionarily between 0x0000 and 0xffff (HEX) or
between 0 and 65535 (DEC)according to the bus and code setting.
Search the matched value prior to current cursor
Search the matched value after current cursor.
-193-
