15. INPUTS / MODULES
Inputs / Modules / Inputs
Adjustment
Description
channel
S1 ... S10 Sensor input selection
Type Sensor type selection
Offset Sensor offset
IMP Impulse input selection
Type Sensor type selection
Inverted Switch inversion
(only when Type = Switch)
Vol./Imp. Impulse rate
Offset Delete offset
Analogue Grundfos Direct Sensor
Ga1, 2
1, 2
Type Grundfos-Direct-Sensor
Max. Maximum pressure (if Type = RPS)
Min. Minimum flow rate (if Type = VFS)
Max. Maximum flow rate (if Type = VFS)
Offset Sensor offset
FR1 Frequency input
Type Sensor type selection
15.3 RC
The RC submenu currently has no function.
Adjustment range /
selection
-
Switch, Fern, BAS, KTY,
Pt500, Pt1000, None
-15.0 ... +15.0 K
-
Impulse, Switch, Fern,
BAS, KTY, Pt500, Pt1000,
None
Yes, No
0.1 ... 100.0 l
Yes, No
TM
-
type RPS, VFS, RH, None
TM
0.0 ... 16.0 bar
1 ... 399 l/min
2 ... 400 l/min
-15.0 ... +15.0 K
-
DN20, DN25, DN32,
VTY20MA, None
175
Factory set-
ting
-
Pt1000
0.0 K
-
Impulse
No
1.0 l
No
-
None
6 bar
2 l/min
40 l/min
0.0 K
-
None
