7. SOLAR
Relay
Solar / Basic setting / Relay
Adjustment
Description
channel
Relay Relay display
PWM/0-10 V PWM/0-10 V option
Output Signal output se-
lection
Signal Signal type
Profile Curve
Speed Speed control
Min. Minimum speed
Max. Maximum speed
Adapter Adapter option
Inverted Inverted switching
option
Blocking pro- Blocking protection
tect. option
Manual mode Operating mode
This submenu indicates the components to which the ouputs of the system selected have been
allocated. All adjustments required for the outputs can be made in this menu.
7.2

OPTIONAL FUNCTIONS

In this menu, additional functions can be selected and adjusted for the solar part of the arrange-
ment.
The kind and number of optional functions offered depends on the previous adjustments.
NOTE:
For further information about adjusting optional functions, see page 108.
Bypass
Pump type Valve type
Output Bypass sensor
Exemplary schematics for the bypass variants
Solar / Opt. functions / Add new function / Bypass
Adjustment
Description
channel
Collector Collector field
Output Bypass output
Type Variant (pump or valve logic)
Inverted Valve logic inversion
Sensor Bypass sensor
Bypass switch-on temperature
DTOn
difference
Bypass switch-off temperature
DTOff
difference
Funct. Activation / Deactivation
Sensor Switch input selection
Adjustment range / se-
lection
system dependent
Yes, No
system dependent
PWM, 0-10 V
Solar, Heating
Yes, No
20 ... 100 %
20 ... 100 %
Yes, No
Yes, No
Yes, No
Max., Auto, Min., Off
Valve type (inverted)
Bypass sensor
Bypass sensor
Output
Output
Adjustment
range / selec-
tion
system dependent system dependent
system dependent system dependent
Pump, Valve
Yes, No
system dependent system dependent
1.0 ... 20.0 K
0.5 ... 19.5 K
Activated, Deacti-
vated, Switch
-
131
Factory setting
system dependent
No
system dependent
PWM
Solar
system dependent
20 %
100 %
No
No
No
Auto
Factory setting
Pump
No
3.0 K
2.0 K
Activated
-
