168
10. HQM
Impulse counter
HQM / Add new function / Impulse counter
Adjustment
Description
channel
Input Impulse input
Carryover Carryover value (for the first-time
configuration or after a reset only)
Funct. Activation / Deactivation
Sensor Switch input selection
With an impulse counter, the impulses of a device with S0 output can be counted, e.g. for bal-
ancing the yield of a PV system.
For this purpose, the impulse input of the controller has to be selected in the Input channel. If
an impulse counter is being configured for the first time or after the overall quantity has been
reset, the parameter Carryover appears. A former value which is to be added to the overall
quantity can be entered.
Adjustment
range / selec- Factory setting
tion
IMP -
- -
Activated, Deacti- Activated
vated, Switch
- -
