4. COMMISSIONING
S1
R1; A
S2
R2 R3
S1
R1; A
S2
R2 R3
S1
S2 S4
R1; A R2; B
System 1.2.3
Sensors
Collector
Store 1 base
Store 2 base
S4
System 1.3.1
Sensors
Collector 1
Store 1 base
Store 2 base
Store 3 base
S4 S5
R4
System 1.3.2
Sensors
Collector 1
Store 1 base
Store 2 base
Store 3 base
S5
R3
Relays; PWM / 0-10 V
S1 Solar pump R1; A
S2 2-PV store 1 R2
S4 2-PV store 2 R3
Relays; PWM / 0-10 V
S1
Solar pump R1; A
S2
2-PV store 1 R2
S4
2-PV store 2 R3
S5
2-PV store 3 R4
Relays; PWM / 0-10 V
S1 Solar pump store 1
S2 Solar pump store 2
S4 Solar pump store 3
S5
R1; A
R2; B
R3
