7. SOLAR
Flow
sensor
Return sensor
Example of flow and return sensor positions
Store heat dump option
This option can be used to direct excess heat generated by strong solar irradiation from the
store to an external heat exchanger (e.g. fan coil) or radiator in order to prevent the collectors
from overheating. The store heat dump function is independent of the solar system and can
be activated with the parameter Heat dump. The function uses the adjustable switch-on and
switch-off temperature differences TStoreOn and TStoreOff.
If the temperature measured at the sensor selected reaches the switch-on temperature, the out-
put selected will be energised until the temperature difference falls below the switch-off value.
7.4

SOLAR EXPERT MENU

The expert menu is only available when the installer user code has been entered.
Solar / Expert
Adjustment
Description
channel
Flow sensor Flow sensor option
Sensor Flow sensor selection
Return sensor Return sensor option
Sensor Return sensor selection
In the expert menu, a flow and a return sensor can be selected and allocated. The activated
sensors are then used to detect the switch-off condition.
NOTE:
Because of the special hydraulics in systems with 2 or 3 collectors, this function will not
work properly there.
Adjustment range /
Factory setting
selection
Yes, No No
system dependent -
Yes, No No
system dependent -
