1. INSTALLATION
FAP13 Outdoor
temperature
sensor
1.4

CENTRAL OUTDOOR SENSOR UNIT

The controller is equipped with an input for a central outdoor sensor unit. The connection is to
be carried out at the terminals marked ZA (any polarity).
Several controllers can use a common outdoor temperature sensor.
The central outdoor sensor unit measures the outdoor temperature and transmits this value to
the controllers connected.
If a central outdoor sensor unit is used, select ZA in the sensor selection under Virtual.
1.5

SD CARD SLOT

The controller is equipped with an SD card slot.
With an SD card, the following functions can be carried out:
• Store measurement and balance values onto the SD card. After the transfer to a computer, the
values can be opened and visualised, e.g. in a spreadsheet.
• Prepare adjustments and parameterisations on a computer and transfer them via the SD card.
• Store adjustments and parameterisations on the SD card and, if necessary, retrieve them from
there.
• Download firmware updates from the Internet and install them on the controller via SD card.
NOTE:
For more information about using an SD card, see page 170.
