Cosmo Multi 3 Montage- Und Bedienungsanleitung Seite 122

122
4. COMMISSIONING
S1 S6
R1 R2
R5
R4
R3; A
S2
S1 S6 S8
R1; A
R2; B
S1 S6 S8
R1 R2
R3; A
System 2.3.5
Sensors
Collector 1
Store 1 base
Store 2 base
Store 3 base
Collector 2
S4 S5
System 3.1.1
Sensors
Collector 1
Store base
Collector 2
Collector 3
R3
S2
System 3.1.2
Sensors
Collector 1
Store base
Collector 2
Collector 3
R4
S2
Relays; PWM / 0-10 V
S1 2-PV collector 1 R1
S2 2-PV collector 2 R2
S4 Solar pump R3; A
S5 3-PV store 1 R4
S6 3-PV store 2 R5
Relays; PWM / 0-10 V
S1 Pump collector 1 R1; A
S2 Pump collector 2 R2; B
S6 Pump collector 3 R3
S8
Relays; PWM / 0-10 V
S1 2-PV collector 1 R1
S2 2-PV collector 2 R2
S6 Solar pump R3; A
S8 2-PV collector 3 R4
