Cosmo Multi 3 Montage- Und Bedienungsanleitung Seite 118

118
4. COMMISSIONING
S1
S2
R1; A R2; B
S1 S6
R1; A
R2; B
S1 S6
R1 R2
R3; A
System 1.4.3
Sensors
Collector 1
Store 1 base
Store 2 base
Store 3 base
Store 4 base
S4 S5 S6
R3 R4
System 2.1.1
Sensors
Collector 1
Store base
Collector 2
S2
System 2.1.2
Sensors
Collector 1
Store base
Collector 2
S2
Relays; PWM / 0-10 V
S1 Solar pump store 1
S2 Solar pump store 2
S4 Solar pump store 3
S5 Solar pump store 4
S6
Relays; PWM / 0-10 V
S1 Pump collector 1 R1; A
S2 Pump collector 2 R2; B
S6
Relays; PWM / 0-10 V
S1 2-PV collector 1 R1
S2 2-PV collector 2 R2
S6 Solar pump R3; A
R1; A
R2; B
R3
R4
