12.9 Service kits

Warning
Before starting work on the pump, make sure that the fuses have been removed or the mains
switch has been switched off. It must be ensured that the power supply cannot be
accidentally switched on.
All rotating parts must have stopped moving.
The service kits in the table below are available for all pumps.
The kits can be ordered as required.
Service kit Contents
Shaft seal kit Shaft seal complete
O-ring kit O-rings and gaskets for oil screws
Grinder head, grinder ring, shaft
Grinder system
screw and locking screw
Impeller complete with adjusting nut,
Impeller
shaft screw and key
1 litre of oil, type Shell Ondina 917.
See section 12. Maintenance and
Oil
service for required quantity in oil
chamber.
Lifting bracket Lifting bracket and screw
Plug for power supply and O-rings for
Power plug
cover
Protective cap Protective cap and O-rings for cover
for level sensor and sensor
Level sensor, protective cap and
Level sensor
O-rings for cover and sensor
Dry-running Dry-running sensor and O-rings for
sensor cover and sensor
Electronic unit Cover with electronics and O-rings for
Single-phase cover
Electronic unit Cover with electronics and O-rings for
Three-phase cover
Pt1000 sensor Pt1000 sensor and bracket
26
Pump type Material
BQQP
SEG.40.09 - 15
BQQV
BQQP
SEG.40.26 - 40
BQQV
NBR
SEG.40.09 - 15
FKM
NBR
SEG.40.26 - 40
FKM
All types
SEG.40.09
SEG.40.12
SEG.40.15
SEG.40.26
SEG.40.31
SEG.40.40
All types
0.9 - 1.5 kW
2.6 - 4.0 kW
All types
All types
Standard pumps
Ex pumps
Standard pumps
Ex pumps
Single-phase
pumps
Single-phase
Ex pumps
Three-phase
pumps
Three-phase
Ex pumps
All types
Product number
96076122
96645160
96076123
96645275
96076124
96646061
96076125
96646062
96076121
96076115
96076116
96076117
96076118
96076119
96076120
96076171
96984147
96984148
96984144
96898081
96898082
96984130
96898083
96984131
96898085
96984145
96898086
96984146
96984143
