4.6 Connection of the Handpieces to the Device
Channel 1 (CH1) allows the connection of
the PIEZOSURGERY medical handpiece
that can be equipped with the sterile,
single-use PIEZOSURGERY
compatible inserts (in accordance with
the manual of each insert).
Channel 2 (CH2) allows the connection of
the PIEZOSURGERY medical+ handpiece
that can be equipped with the sterile,
single-use PIEZOSURGERY
compatible inserts (in accordance with
the manual of each insert).
Insert the handpiece connector into
the suitable port located on the front
panel of the device, assuring that the
index point on the connector is aligned
with the index point on the ring nut of
the connector port. Gently push the
handpiece connector until it is completely
inserted;
CAUTION: To avoid damaging
the cord-handpiece, connect and/
or disconnect it, holding it by the
connector only. Never pull the cord.
18
1
medical
medical+
CH 1
CH 2
