CAUTION: No changes to this device
nor to its accessories are allowed.
WARNING: Before using the
PIEZOSURGERY medical irrigation kit, check
the integrity of the sterile packaging and
inspect the product to exclude the presence
of any damage. Do not use the irrigation kit
4.2 Device Installation
Equipotential plug: there is an additional
equipotential plug on the back of the
device. The plug complies with DIN
42801. Insert the equipotential cable
connector (not supplied) onto the plug
on the back of the device. The purpose of
the additional equipotential connection
is to reduce the difference in potential
that may occur during operation between
the device body and the conductive
parts of other objects within the medical
environment;
Insert the power supply cord into its
connector on the back of the device and
then into the wall socket;
CAUTION: Position the device in
such a way as to ensure that the plug
is easily accessible as this is considered
a means for disconnecting the power
supply.
Connect the foot pedal to the back of
the device in the socket marked with
the symbol , using the foot pedal
cable plug, ensuring it clicks into place.
To disconnect the foot pedal from the
machine body, grasp the connector, crush
the release sleeve and pull backwards;
NOTE: if the foot pedal ceases
functioning, the button on the back,
left of the device, below the symbol
, can be used to continue treatment.
INSTALLATION AND CONFIGURATION
if the packaging is open or damaged. The
irrigation set loses sterility if the packaging
is broken or damaged. If the packaging is
damaged or unintentionally opened before
the use, proceed with the disposal of the
set. The product cannot be re-sterilized or
reused.
1
2
3
13
