Symbol Description
Equi-potentiality
I Activation switch "on"
Graphic symbol intended
to identify the Channel
1 (CH1) used to connect
the PIEZOSURGERY
medical handpiece.
International Protection
Code of the mechanical
IPX8
casing. Liquid ingress
protection.
Irrigation
Connection of the foot
pedal
Do not touch moving
parts
Temperature limit
Fragile
Keep dry
For US market only
CAUTION: Federal
(US) law restricts the
Rx Only
marketing of this device
to prescription or
licensed practitioner.
a) The combined use of these symbols is used on the
device identification label to represent intermittent
operation.
8
a)
a)
b)
Symbol Description
Functional earth
0 Activation switch "off"
Graphic symbol
intended to identify
the Channel 2 (CH2)
used to connect the
PIEZOSURGERY medical
+ handpiece.
International Protection
IP20 Code of the mechanical
casing.
Clock, time switch,
timer
Warning electricity
General warning
Humidity limitation
Atmospheric pressure
limitation
This way up
Do not use if package is
damaged
b) The symbol is represented by a red circle-with-slash and
a black graphical symbol.
c) The symbol is represented by a yellow warning triangle
and a black graphical symbol.
a)
c)
