MOUNTING SETS (OPTIONAL)
Precaution:
For truck chassis specific mounting kits please consult Hyva document
HKL-0003.
Precaution:
Bolt sets to bolt the sub frame support to the chassis bracket are not
supplied as standard, but can be ordered separately (OT60108).
FIXED MOUNTING
Subframe support
OT60101
14 mm
AE070238 (4x)
AE070695
OT60103
16 mm
AE070238 (4x)
AE070697
T20/22-xx-S/SK & T26/30-47/49/51-S & T26/30-49/51/53-SK
OT60101
14 mm
AE080160 (4x)
AE080701
OT60103
16 mm
AE080160 (4x)
AE081139
OT60101
14 mm
AE090092 (0x)
AE090701
OT60103
16 mm
AE090092 (0x)
AE090800
*
Delivered including fastener sets to connect to subframe (+24 fastener sets M14x40 DIN933)
Subject to change without notice
TITAN HOOKLOADER
INSTALLATION MANUAL
Front support
T-12/18-xx-S
*
AE080159 (4x)
*
AE080159 (4x)
*
AE080159 (4x)
*
AE080159 (4x)
T26/30-53+-S & T26/30-55+-SK
AE080159 (6x)
AE080159 (6x)
Table 2.5 Fixed mounting sets
11
Chassis support
AE080167 (8x)
AE080166 (2x)
AE080145 (8x)
AE080166 (2x)
AE080167 (8x)
AE080166 (2x)
AE080145 (8x)
AE080166 (2x)
AE080167 (8x)
AE080166 (2x)
AE080145 (8x)
AE080166 (2x)
OH-E HKL-0002 / 25-05-2020 / RV AB
