Interface for sensors and synchro bus
View from the front on the contacts:
Pin
1
2
3
4
5
6
7
8
Motor slot
View from the front on the contacts:
Pin
1
2
3
4
5
6
7
8
90
Function
GND -
RS485 B Serial interface for communication
between controls (Sync-BUS)
Sensor 2 No function saved
Sensor 1 Safety edge (see chapter 6.5.6.5)
12 VDC 12 V ± 10% max. 20 mA
RS485 A Sync-BUS
Sensor 3 No function saved
Sensor 4 Set external stop (see chapter 6.5.6.6)
Function
Motor +
Lower limit switch
+12 VDC
Hall sensor A
Hall sensor B
Upper limit switch
GND
Motor -
MultiControl II duo and MultiControl II quadro assembly instructions
Description
Description
0 ... 28.5 VDC Drive control (output)
Signal contact input. +12 VDC is present here if the
limit switch is not actuated (contact type: NC). The
connected limit switch contact is open in the end
position.
Supply for hall sensors and limit switch (output)
Hall sensor signal inputs. Hall sensor output type:
open collector.
Signal contact input. +12 VDC is present here if the
limit switch is not actuated (contact type: NC). The
connected limit switch contact is open in the end
position.
Supply for hall sensors (output)
0 ... 28.5 VDC Drive activation (output)
Core colour
brown
Green
white
Grey
Pink
yellow
black
blue
