MultiControl II duo and MultiControl II quadro assembly instructions
1 Operating runtime
2 Error number
3 Error type
4 Time of error
within the runtime
5 Labelling function key 2
(leave display)
In the time stamp, the operating hours counter is shown in "days and
hour : minute : second". The time of an error during the runtime is documented
with the corresponding time stamp.
The error history display as shown in Figure 14 provides the following information:
• The control has been operating for 32 days, 1 hour, 32 minutes, and 57
seconds. (Figure 14, No. 1)
• The second error within the runtime is currently being displayed. (Figure
14, No. 2)
• The error that has occurred is error E38 (for its meaning, see chapter
6.10).(Figure 14, No .3)
• The error was documented at a runtime of 31 days, 2 hours, 37 minutes,
and 15 seconds (Figure 14, no. 4). The moment of the error can be
calculated from the difference between
the current operating runtime (32 days
01:32:57) and the time of the error
within the runtime (31 days 02:37:15).
Accordingly, the error occurred 22 hours,
55 minutes, and 42 seconds ago.
If drive group management is activated, the errors
related to the corresponding drive groups - as can be
seen in - are saved and displayed.
1
2
Figure 14 - Display for error history
Figure 15 - Categorised error
history
3
4
5
